Main WheelBF GoodrichCMM 32-45-51

3-1607/3-1607-1/3-1607-1T1

Name: 3-1607/3-1607-1/3-1607-1T1 — Cessna Main Wheel
Brand: BF Goodrich
SKU: 3-1607/3-1607-1/3-1607-1T1
Availability: InStock

Cessna

Citation CJ3, CJ3+, Encore

Alternative Part Number9912561-4·9912561-5·9912561-6

Variants3-1607·3-1607-1·3-1607-1T1

Book Your Service Today

(214) 337-3328AOG support available

This CMM Covers Multiple Variants

This CMM covers multiple wheel variants. Effectivity codes (A, B, C…) in the parts list map to the variants shown below.

3-1607

3-1607-1

Gray Paint

3-1607-1T1

White Paint

Overview

The 3-1607 is a main wheel assembly used on Cessna Citation CJ3, CJ3+, Encore. Manufactured by Goodrich.

Material

Aluminum

Manufacturer

BF Goodrich

CMM Reference

32-45-51

Aircraft

Cessna

Maintenance Schedule

Eddy Current / NDTEvery tire change

OverhaulThe inspection intervals are calculated as follows: 750 (landings between NDT inspections) divided by 250 (landings between tire changes) = 3 (number of tire changes between ADDED INSPECTIONS). If the

Wear Pointsbearings, o-ring grooves, corrosion

Penetrant Inspection → Overhaul

Per CMM: Per CMM, any wheel requiring penetrant inspection is processed as an overhaul. Owners may elect overhaul at any tire change to extend service life.

Parts Replaced at Tire Change

Every tire change replaces the tire, the main wheel-half preformed packing (O-ring), the valve cap, and the valve core. Specific part numbers and dash sizes vary by wheel and are pulled from the CMM at the time of service.

Always Replaced

Seals & O-Rings

68-1482O-ringQty 1

Hardware

TRVC5Cap, ValveQty 1

TRC4Core, ValveQty 1

Replaced If Needed

Seals & O-Rings

TRRG30O-ringQty 1

During tire change or NDT inspection, additional parts beyond the routine four may require replacement if they fail inspection or meet the rejection criteria defined in the CMM.

Parts Replaced at Overhaul

A full overhaul includes all parts replaced at tire change (listed above), plus the following components inspected and replaced per the CMM:

Seals & O-Rings

NAS1611-014O-ringQty 2

68-450O-ringQty 1

MS9386-006O-ring (Used with Item 85 only)Qty 1

68-1606O-ring (Used with Item 85A only)Qty 1

Fuse Plugs

542-6Plug Assembly, Thermal Relief (Supsds Item 85)Qty AR

49-138Plug, Thermal Relief (Used with Item 85 only) (Part is plated with cadmium) (Nonprocurable)Qty 1

49-410Plug, Thermal Relief (Used with Item 85A only) (Nonprocurable)Qty AR

Hardware

50-734Plate, IdentificationAQty 1

50-862Plate, IdentificationBQty 1

50-992Plate, IdentificationCQty 1

50-880Plate, Instruction (Repls Item 42) *Refer to the AMM for the correct installation of these partsQty 1

50-748Plate, Instruction *Refer to the AMM for the correct installation of these partsQty AR

50-748Plate, InstructionQty 1

Other Parts on the Wheel

These components are part of the wheel assembly but are not replaced during a standard tire change or overhaul. They are only replaced when inspection per the CMM identifies a rejectable condition. APSS stocks or sources these parts on request — contact us for current availability.

Bearings

LM503349A20629Cone, Bearing (True P/N is LM503349A-20629)Qty 2

LM503310-20629Cup, Bearing (refer to paragraph 4.)Qty 2

Seals & O-Rings

68-1316Assembly, Grease SealQty 2

Fasteners

53-388Clip, RetainingBQty 1

MS24693S269Screw (Part is plated with cadmium)Qty AR

MS21083N3Nut, Self-Locking (Part is plated with cadmium)Qty AR

AN960-10Washer, Flat (Part is plated with cadmium)Qty AR

MS24693S273Screw (Part is plated with cadmium)Qty AR

AN502-10-8Screw (Repls Item 905) (Part is plated with cadmium)Qty AR

NAS1149F0332PWasher, Flat (Repls Item 910) (Part is plated with cadmium)Qty 3

MS20426A4-4RivetQty 2

Hardware

TR760-03Valve Assembly, Inflation (refer to paragraph 5.)Qty AR

TR760-02Stem, Valve (refer to paragraph 5.)Qty AR

49-336Plug, Overinflation (Includes 2 of Item 75)Qty 1

53-387Clip, Lock RingBQty 1

245-601Ring, LockAQty 1

245-693Ring, LockBQty 1

11-128Rim, Side (Gray Paint)A, BQty 1

11-128T1Rim, Side (White Paint)CQty 1

4691-3CN254Twinsert® (Service Part) (Order Item 135B with this part)Qty AR

SR192LSlimsert®Qty 3

SRW192LSlimsert® (Oversized) (Service Part)Qty AR

97-148-1Weight, Balance (1/2 oz.) (Part is plated with cadmium)Qty AR

118-146Cap Assembly, Hub (Gray Paint)A, BQty 1

118-146T1Cap Assembly, Hub (White Paint)CQty 1

40-91115Coupling, Drive (Part can contain beryllium)Qty AR

32-570Cap, Hub (Nonprocurable)Qty 1

68-1463GasketQty 1

Wheel Components

The structural components of the wheel assembly itself. These are not replaced on a standard service and come into play only when damage, corrosion, or cracks exceed the repair limits established by the CMM.

Wheel Halves

300-924Wheel Base Assembly (Gray Paint)A, BQty 1

300-924T1Wheel Base Assembly (White Paint)CQty 1

10-1711Wheel Base (Nonprocurable)Qty 1

Wheel Components

170-605InsertAQty 6

170-667Insert (Oversized) (Service Part)B, CQty AR

3591-3CN190Insert, Heli-Coil®Qty 6

3891-3CN285Insert, Heli-Coil® (Oversized) (Service Part)Qty AR

Inspection Criteria

General

General overhaul criteria — see the CMM for full specifications and numeric limits:

Drive keys: replace if damaged, corroded, or loose.
Heat shield: replace if cracked, burned, or mechanically damaged.
Bolts and nuts: replace if cracked, corroded, thread-damaged, or failing the back-off torque test.
Bearings (cones and cups): replace if spalled, discolored from heat, pitted, or showing any surface wear.
Wheel halves: replace if cracked, out-of-round beyond CMM limits, or showing seal-groove damage.
Preformed packings and O-rings: replace at every disassembly.
Retaining rings and lockwire: replace whenever removed.
